2-1
2. INSPECTIONS/ADJUSTMENTS
SERVICE INFORMATION
WARNING
•The exhaust gas contains poisonous substance. Do not keep engine idling in a closed or poorly ventilated place for a
long period of time.
SPECIFICATIONS
TORQUE VALUES
SPARK PLUG
1.4㎏f·m
CYLINDER HEAD COVER BOLTS
1.0㎏f·m
2
SERVICE INFORMATION 2-1
REGULAR INSPECTION SCHEDULE
2-2
FUEL LINE (FUEL TUBE)
2-3
FUEL LINE FOR CLOGGING
2-3
THROTTLE GRIP OPERATION
2-3
AIR CLEANER
2-4
SPARK PLUG
2-5
CYLINDER COMPRESSION PRESSURE
2-5
CARBURETOR IDLING
2-6
AIR SCREW ADJUSTMENT
2-6
BRAKE FLUID
2-6
BRAKE PAD/SHOE
2-7
BRAKE SYSTEM
2-7
HEADLIGHT ADJUSTMENT
2-8
SIDE STAND
2-8
SUSPENSION
2-9
BOLTS, NUTS, FASTENERS
2-9
WHEELS/TIRES
2-9
STEERING HEAD BEARING
2-10
BATTERY
2-10
ITEM STANDARD VALUE REFERANCE
THROTTLE GRIP FREE PLAY 2-6mm
SPARK PLUG B8HSA
SPARK PLUG GAP 0.6〜0.7mm
CARBURETOR IDLE SPEED 1,800±100rpm
CYLINDER COMPRESSION PRESSURE 10㎏f/㎠ - 600rpm
NOTE
•Stand the main stand prior to beginning work.
