CHARGING DEVICE LOCATION
13-2
BATTERY/CHARGING SYSTEM
TUBELESS
TIRE
APPL.
KOREA
BATTERY
FUSE
RESISTER
REGULATOR/ RECTIFIER
A.C.GENERATOR
WHITE
YELLOW
GREEN
GREEN
BATTERY
LIGHTING SWITCH
REGULATOR/
RECTIFIER
BROWN
BROWN
GREEN /
BLACK
RESISTER
5W 6.7
RESISTER
30W 5.9
HEADLIGHT
(12V 35/35W)
METERLIGHT
(12V 1.7WX2)
AUTO-
BYSTARTER
WHITE
BLUE
PINK
DIMMER
SWITCH
RED
7A FUSE
A.C.GENERATOR
