4-1
4. LUBRICATION SYSTEM
SERVICE INFORMATION
CAUTION
·Remove air from oil tube and oil pump if the oil tube is taken off or if air enters the oil tube.
● If the oil tube is disassembled, remove the air in the oil pass tube.
● Maintenanace on the oil pump is done without the engine being removed from the vehicle.
● When disassembling the oil pump, do not allow foreign substances from entering the engine or oil pump.
● Do not disassemble the oil pump assembly.
● If the oil tube is disassembled, place a tube clip or band on the oil tube to prevent oil from leaking out.
TROUBLESHOOTING
Overheating or engine clogging
● Faulty adjustment of oil pump(insufficient amount pumped).
● Bad quality of engine oil.
● Engine oil not being injected or blocked, bent strainer screen or oil tube.
● Entering of air in oil tube system.
● Faulty oil pump.
● Engine oil not being supplied from oil tank.
-Blocked oil tank cap air hole
-Blocked oil strainer screen
Excess exhaust smoke, accumulation of carbon on spark plug
● Faulty adjustment of oil pump(over-pumped amount).
● Bad quality of engine oil.
4
SERVICE INFORMATION 4-1
TROUBLESHOOTING
4-1
OIL SYSTEM DRAWING
4-2
OIL PUMP DISASSEMBLY/
ASSEMBLY
4-3
OIL PUMP INSPECTION/
ADJUSTMENT
4-3
OIL PUMP BLEEDING 4-4
ENGINE OIL LEVEL INSPECTION
4-6
TRANSMISSION OIL INSPECTION
4-7
OIL TANK DISASSEMBLY
4-8
LUBRICATION POINTS
4-9
