IGNITION DEVICES LOCATION
14-2
IGNITION SYSTEM
SPARK PLUG
IGNITION
MAIN SWITCH
II
VV
SIDE STAND SWITCH
BLUE / YELLOW
PULSE GENERATOR
AC GENERATOR
MAIN SWITCH
SIDE STAND
SWITCH
IGNITION COIL
SPARK PLUG
BLACK / YELLOW
BLACK / WHITE
BLACK / RED
GREEN
CDI UNIT
