STARTING DEVICES LOCATION
15-2
STARTING SYSTEM
TUBELESS
TIRE
APPL.
KOREA
BATTERY
STARTER RELAY
FUSE 7A
MAIN
SWITCH
STARTER
SWITCH
STARTER MOTOR
RED/WHITE
YELLOW/RED
GREEN/YELLOW
GREEN/YELLOW
BATTERY
FRONTSTOP
SWITC
H
STARTER
RELAY
MAINSWITCH
RED
GREEN
GREEN
BLACK
FUSE
REARSTOPSWITCH
STARTER
SWITCH
STARTER
MOTOR
