● For adjustment, loosen the lock nut and turn adjuster.
● After adjusting, tighten lock nut. After adjustment is
completed, recheck the throttle grip free play.
AIR CLEANER
● Loosen the 5 setting screw assembled to the air cleaner
case cover, and then remove the air cleaner case cover.
● Remove the air cleaner element.
● Wash away any accumulated dust or dirt, by gently
squeezing it in non flammable or high flash point
solvent.
WARNING
•Using gasoline or low flash point solvents for
cleaning parts may result in a fire or explosion.
CAUTION
•Cleaning the element with gasoline or any acid,
alkaline, or organic, volatile type oil may cause
improper ignition, deterioration of the element, or a
loosening of the element adhesive.
● Be sure to allow the element to dry thoroughly before
applying oil. Otherwise, the oil will be diluted by the
and the filtering ability of the filter will be much
less effective.
● Spread clean #80~90 gear oil on the element, rubbing
inthoroughly over the surface with both hands, and then
squeeze out any excess oil.
CAUTION
•Using air filter oil when riding in extremely dusty
conditions prevents premature engine wear due to
dust/dirt drawn into the engine. Apply air filter oil to
the entire surface of the element and rub it with both
hands to saturate the element with oil. Squeeze out
excess oil.
2-4
INSPECTIONS/ADJUSTMENTS
