DAELIM S-FIVE Service Manual

13-3
BATTERY/CHARGING SYSTEM
TROUBLESHOOTING
Battery is Overcharged
● Headlight bulb is out.
● No headlignt beam wire.
● Headlight register is damaged (disconnected).
● Lighting switch is connected incorrectly.
● Regulator/rectifier is not grounded or connected incorrectly.
Problems with the Charging System
Measure battery voltage leakage.
Inspect the body of the register/rectifier.
Battery is damaged.
Wire harness is short-circuited.
Coupeler is connected incorrectly.
Short-circuited harness.
Damaged main switch.
Regulator/rectifier is damaged.
Check the AC generator charging coil
Inspact the AC generator charging/
lighting coil
Damaged regulator/ rectifier
(darkened headlight)
Damaged headlight register.
Damaged regulator/ rectifier.
Damaged Battery
Check charge level.
Check the voltage of the regulator/rectifier
battery lines and the ground line.
Check the changing coil with the regulator/
rectifier coupler charging coil.
Check the lighting coil at the regulator/
rectifier coupler lighting coil line.
Check the headlight lighting control voltage.
Inspect the headlight register.
Inspect the body of the register/rectifier.
NORMAL
ABNORMAL
ABNORMAL
NORMAL
AC generator coupler connected incorrectly.
Damaged charging coil.
ABNORMAL
NORMAL
AC generator coupler connected incorrectly.
Damaged charging/lighting coil.
ABNORMAL
NORMAL
ABNORMAL
ABNORMAL
ABNORMAL
ABNORMAL
ABNORMAL
ABNORMAL
OVER 15V
OVER 14~15V
UNDER 14V
NORMAL
NORMAL
NORMAL
NORMAL
NORMAL
NORMAL
