DAELIM S-FIVE Service Manual

11-1
11. REAR WHEEL/BRAKE/SUSPENSION
SERVICE INFORMATION
GENERAL SAFETY
● If the brake drum or lining is contaminated with oil, braking power will be lost. If contaminated with oil, clean the brake
drum, and replace the brake shoe.
● Inhaled asbestos fibers have been found to cause respiratory disease and cancer. Never use an air hose or dry brush to
clean brake assemblies. Use a brake cleaner, designed to minimize the hazard caused by airborne asbestos fibers.
SPECIFICATIONS
TORQUE VALUES :
AXLE SHAFT RUN OUT 10.0~12.0㎏f·m
REAR CUSHION UPPER BOLT 3.5~4.5㎏f·m
REAR CUSHION LOWER BOLT 3.5~4.5㎏f·m
11
SERVICE INFORMATION 11-1
TROUBLESHOOTING
11-2
REAR WHEEL 11-3
ITEM STANDARD VALUE SERVICE LIMIT
AXLE SHAFT RUN OUT - 0.2 mm
REAR WHEEL RIM RUNOUT
- 2.0 mm
- 2.0 mm
REAR BRAKE DRUM INNER DIAMETER 110.0~110.3mm 111.0mm
REAR BRAKE LINING THICKNESS 4.0 mm 2.0 mm
REAR CUSHION SPRING FREE LENGTH 234.8mm 228.0mm
RADICAL
AXIAL
REAR BRAKE 11-4
REAR CUSHION
11-6

DAELIM S-FIVE Specifications

General

Fuel System	Carburetor
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Tires (Front)	120/70-12
Tires (Rear)	130/70-12
Engine Type	4-Stroke, Air-Cooled
Transmission	Automatic
Fuel Capacity	5.5 liters
