REAR BRAKE FREE PLAY ADJUSTMENT
● Turn the adjuster nut to adjust the free play.
● After initial adjustment, check the operation of the rear
brake light switch. Make additional adjustments, if
necessary.
HEADLIGHT ADJUSTMENT
● Adjust the headlight beam level by operating the
adjusting screw located on the upper side of the front
fender.
NOTE
•Adjust the beam level according to local laws and
regulations.
•Improper beam level adjustment may blind
oncoming drivers, or may incorrectly light the road
ahead.
SIDE STAND
● Erect the main stand.
● Pull the lower end of the side stand, and see if it moves
freely.
● If the side stand does not move smoothly, apply grease
to the pivot area.
● If the side stand moves too freely, check the side stand
spring.
● Check the axial movement of the side stand.
● Check the side stand ignition cut-off switch :
-Put the side stand up.
-Start the engine.
-Lower the side stand. The engine should stop as you
put the side stand down.
● If there is a problem with the system, check the side
stand switch.
2-8
INSPECTIONS/ADJUSTMENTS
