15-1
15. STARTING SYSTEM
SERVICE INFORMATION
GENERAL SAFETY
WARNING
·When performing maintenance on the starter motor and related parts, turn the main switch to OFF. There is the
danger of the starter motor unexpectedly operating if the main switch is not turned to OFF.
First check connection with battery and battery charge level before beginning maintenance on the starter motor.
It is possible for the starter motor coil to become damaged if the starter is operated when the engine does not turn over.
15
SERVICE INFORMATION
15-1
STARTING DEVICES LOCATION
15-2
TROUBLESHOOTING
15-3
STARTER MOTOR
15-4
STARTER RELAY INSPECTION
15-7
STARTER PINION GEAR INSPECTION
15-7
