DAELIM S-FIVE Service Manual

6-1
6. ENGINE REMOVAL/INSTALLATION
SERVICE INFORMATION
GENERAL SAFETY
NOTE
•Use a jack to remove or install the engine. Support the motorcycle with a jack firmly, taking precautions not to
damage the frame, engine, cable or harness.
•Attach tape to the frame to protect it during the engine removal or installation.
● The following works can be carried out without removing the engine from the vehicle body.
-TRANSMISSION (⇨SECTION 9)
-A.C. GENERATOR (⇨SECTION 13)
-KICK STARTER/ CONTINUOUSLY VARIABLE TRANSMISSION (⇨SECTION 7)
-CYLINDER HEAD/ CYLINDER/ PISTON (⇨SECTION 8)
-CARBURETOR (⇨SECTION 5)
-OIL PUMP (⇨SECTION 4)
● Items to be worked after removing engine
-CRANKSHAFT, CRANKSHAFT BEARING, CRANK CASE BEARING.
TORQUE VALUES :
ENGINE HANGER BOLT (ENGINE) : 5.0㎏f·m
(FRAME) : 7.3㎏f·m
6
SERVICE INFORMATION 6-1
ENGINE REMOVAL/INSTALLATION
6-2
ENGINE HANGER LINK REMOVAL
6-3

DAELIM S-FIVE Specifications

General

Fuel System	Carburetor
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Tires (Front)	120/70-12
Tires (Rear)	130/70-12
Engine Type	4-Stroke, Air-Cooled
Transmission	Automatic
Fuel Capacity	5.5 liters
