DAELIM S-FIVE Service Manual

1-12
SERVICE INFORMATION
ITEM STANDARD
CLUTCH
CLUTCH AUTOMATIC
TYPE
CLUTCH OUTER DIAMETER
CLUTCH LINING THICKNESS
DRIVE BELT WIDTH
MOVABLE DRIVE FACE
BUSH INSIDE DIAMETER
BOSS OUTSIDE DIAMETER
WEIGHT ROLLER OUTSIDE DIAMETER
DRIVEN PULLEY FACE SPRING FREE LENGTH
FACE OUTSIDE DIAMETER
MOVABLE FACE INSIDE DIAMETER
CRANK SHAFT
CRANK SHAFT LARGE END SIDE CLEARANCE
CONNECTING ROD LARGE END RIGHT
ANGLE DIRECTION CLEARANCE
CRANK SHAFT SHAKING A
B
FRONT, REAR WHEELS
WHEELS RIM RUNOUT RADICAL
AXIAL
AXLE DEFLECTION
TIRES TYPE
TIRE PRESSURE FRONT
REAR
TIRE SIZE FRONT
REAR
SUSPENSION
FRONT FRONT CUSHION FREE LENGTH
REAR REAR CUSHION FREE LENGTH
BRAKES
FRONT BRAKE LEVER FREE PLAY
BRAKE FLUID
BRAKE PAD THICKNESS
DISK THICKNESS
DISK SHAKING
DISK WEAR LINE
MASTER CYLINDER INSIDE DIAMETER
MASTER PISTON OUTSIDE DIAMETER
CALIPER CYLINDER INSIDE DIAMETER
CALIPER PISTON OUTSIDE DIAMETER
REAR BRAKE LEVER FREE PLAY
DRUM INSIDE DIAMETER
LINING THICKNESS
Automatic Centrifugal
Continuously Variable Transmission
107.0-107.2mm
3.0mm
17.5mm
20.035-20.085mm
20.011-20.025mm
15.920-16.080mm
98.1mm
33.965-33.985mm
34.000-34.025mm
0.15~0.55mm
0.010~0.02mm
0.03mm(70mm fromcenter)
0.05mm(40mm fromcenter)
-
-
-
TUBELESS
1.75㎏
f/㎠ (2.00㎏f/㎠)
2.00㎏
f/㎠ (2.25㎏f/㎠)
120/70-12 58L
130/70-12 62L
263.5mm
234.8mm
10~20mm
DOT3 or DOT4
-
3.5mm
-
3.0mm
11.000-11.043mm
10.957-10.984mm
30.230-30.280mm
30.148-30.198mm
10~20mm
110mm
4.0mm
-
-
107.5mm
2.0mm
16.5mm
20.60mm
19.97mm
15.40mm
92.8mm
33.94mm
34.06mm
0.60mm
0.04mm
0.15mm
0.10mm
2.0mm
2.0mm
0.2mm
-
-
-
-
256.0mm
228.0mm
-
-
to wear line
3.0mm
0.3mm
11.05mm
10.91mm
30.29mm
30.14mm
-
111mm
2.0mm
USE LIMITS

DAELIM S-FIVE Specifications

General

Fuel System	Carburetor
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Tires (Front)	120/70-12
Tires (Rear)	130/70-12
Engine Type	4-Stroke, Air-Cooled
Transmission	Automatic
Fuel Capacity	5.5 liters
