DAELIM S-FIVE Service Manual

● Insert the brush spring into the brush holder and install
the front bracket.
NOTE
·Insert the brush spring with care so that it does not
lean in the holder.
● Apply grease to both ends of the armature shaft.
● Install the starter motor cover.
NOTE
·The coil may be damaged if the magnet pulls the
armature against the case.
● Align the front bracket with the cover.
● Tighten the washer screw.
15-6
STARTING SYSTEM
BRUSH HOLDER
GREASE
STARTER MOTOR COVER
WASHER SCREW

DAELIM S-FIVE Specifications

General

Fuel System	Carburetor
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Tires (Front)	120/70-12
Tires (Rear)	130/70-12
Engine Type	4-Stroke, Air-Cooled
Transmission	Automatic
Fuel Capacity	5.5 liters
