9-1
9. A.C GENERATOR / STARTER CLUTCH
SERVICE INFORMATION
● Drain the coolant before removing the right crankcase cover.
● Be careful not to drain the coolant when the engine temperature in high. (Perform this operation when the engine is
cold.)
● Drain the engine oil into a clean container before removing the right crankcase cover.
● When the right crankcase cover is installed, fill with the recommended engine oil and coolant.
● Then, bleed air from the water jacket.
SPECIFICATIONS
9
SERVICE INFORMATION
··········
9-1
R. CRANKCASE COVER REMOVAL
··
9-2
STARTER CLUTCH
················
9-3
FLYWHEEL INSTALLATION
······
9-4
STATOR INSTALLATION
··········
9-5
R. CANKCASE COVER INSTALLATION
··
9-5
22.026~22.045mm
42.195~42.208mm
22.15mm
41.5mm
ITEM
Large end side clearance
Connecting rod large end right angle direction clearance
STANDARD SERVICE LIMIT
TORQUE VALUES
FLYWHEEL NUT : 5.39~6.37kgf·m
