A.C GENERATOR/STARTER CLUTCH

STATOR REMOVAL

● Remove the three A.C. generator stator bolts and the

stator.

FLYWHEEL REMOVAL

● Hold the flywheel with a flywheel holder and remove

the flywheel nut.

RIGHT CRANKCASE COVER

REMOVAL

● Disconnect the water hoses from the right crankcase

cover.

● Remove the 9 bolts securing the right crankcase cover

and the cover.

● Loosen the 2 puler coil screws and disconnect pulser

coil.

● Remove the flywheel with a flywheel puller.

·When removing the pulse coil and stator, be careful

not to damage them to avoid shorted or broken wire.

BOLTS

WATER INLET HOSE

SCREWS

PULSE COIL

A.C. GENERATOR STATOR

BOLTS

FLYWHEEL

FLYWHEEL PULLER

FLYWHEEL HOLDER
