● Install the dust seal.
● Fill a prescribed amount of automatic transmission
fluid(ATF) into the fork tube.
CAPACITY : 90cm
3
● Slowly press the fork tube 2-3 times to discharge air.
● Install the oil seal stopper ring
● Accurately assemble the oil seal stop ring to the bottom
case.
● Assemble the spring to the fork pipe.
● Assemble the fork bolt to the fork pipe.
14-18
FRONT WHEEL/FRONT FORK/STEERING/BRAKE
·Install the spring with the smaller pitch side facing
downward.
FORK OIL
OIL
LEVEL
FORK
OIL
OIL SEAL
STOPPER RING
OIL SEAL
STOPPER RING
OIL SEAL
STOPPER RING
OIL SEAL
STOPPER RING
OIL SEAL
STOPPER RING
OIL SEAL
STOPPER RING
OIL SEAL
STOPPER RING
OIL SEAL
STOPPER RING
OIL SEAL
STOPPER RING
OIL SEAL
STOPPER RING
OIL SEAL
STOPPER RING
OIL SEAL
STOPPER RING
OIL SEAL
STOPPER RING
OIL SEAL
STOPPER RING
OIL SEAL
STOPPER RING
OIL SEAL
STOPPER RING
OIL SEAL
STOPPER RING
OIL SEAL
STOPPER RING
FORK PIPE CAP BOLT
FORK PIPE CAP BOLT
FORK PIPE CAP BOLT
FORK PIPE CAP BOLT
FORK PIPE CAP BOLT
FORK PIPE CAP BOLT
FORK PIPE CAP BOLT
FORK PIPE CAP BOLT
FORK PIPE CAP BOLT
FORK PIPE CAP BOLT
FORK PIPE CAP BOLT
FORK PIPE CAP BOLT
FORK PIPE CAP BOLT
FORK PIPE CAP BOLT
FORK PIPE CAP BOLT
FORK PIPE CAP BOLT
FORK PIPE CAP BOLT
FORK PIPE CAP BOLT
