16-5
CHARGING SYSTEM
REGULATOR RECTIFIER INSPECTION
Remove the luggage box.
Remove the regulator rectifier coupler.
Measure each terminal.
Replace the regulator rectifier unit if the resistance
value between the terminals is abnormal.
RESISTANCE VALUE
Tester
Tester
Unit : ㏀,(
20
)
R
B
Y
Y
Y
G
R
B
0-5
1-4
1-4
1-4
25-40K
Y
1-3
Y
1-3
Y
1-3
G
1-4
25-40K
1-4
1-4
1-4
