DAELIM S2 250

18-3
STARTER SYSTEM
DISASSEMBLY
● Release the two starter motor case screws, front cover,
rear cover, motor case and other parts.
INSPECTION
● Inspect the removed parts for wear, damage or
discooration. Replace if necessary.
● Clean the commutator if there is metal powder between
the seaments.
● Check for continuity between pairs of the commutator
segments and there should be continuity.
STARTER MOTOR
● Release the seat lock with the main key.
● Remove the luggage box.
● Remove the core tubeband from the carbureter
● Remove the starter motor cable from the starter
magnetic switch.
● Loosen the 2 flange bolts securing the engine case,
remove the battery earth cable and starter motor.
● Install in the reverse order of removal.
