18-4
STARTER SYSTEM
● Measure the length of the brushes.
SERVICE LIMIT : 8.5m replace if below
● Check the continuity between brush ⊕and cord
terminal.
- Normal if there is continuity.
● Check the continuity between cord terminal and case.
- Normal if there is no continuity.
● Make a continuity check between individual
commutator segments and the armature shaft. There
should be no coninuity.
