95XF series Removal and installation
EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES
4-27
12. Slide t he hub over the axle journal. Do not
pry, as the oil seal (14) might be damaged
in the process.
13. Fit the adjusting nut (6) to the axle journal.
14. Adjust the s pecified wheel bearing play (see
chapter “Inspection and adjustment”) and fit
the c irclip (5) to the axle journal.
15. Fit a new locking washer (4) to the axle
journal. The washer cam (see the arrow)
should c atch in one of the holes of the
circlip (5).
S7 00 402
5
4
16. Fit the lock nut (3) to the axle journal.
Tighten the lock nut (3) to the specified
tightening torque. See “Technical data”. Use
a s ocket spanner (A) for this, special tool
(DAF no. 0535832).
17. Secure lock nut (3) by tapping back the
locking washer (4) against the side of the
lock nut.
18. Apply the specified grease to the front of the
outer wheel bearing.
19. Clean the hub (9) sealing surfaces and the
hub cap (2), and make sure they are dry
and free of grease.
20. Apply a locking compound to the hub (9)
sealing f ace.
21. Fit the hub cap (2). Tighten the bolts (1) to
the s pecified torque. See “Technical data”.
A
S7 00 087
22. Press the wheel speed sensor (11) up
against the sensor ring (10). While the
vehicle is being driven, the air gap between
the wheel speed sensor (11) and the sensor
ring (10) is adjusted automatically.
23. Adjust the brakes.
S7 00 403
10 11
5
200424
