EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES
Removal and installation 95XF series
4-28
LEADING REAR AXLE 09N044 (FTP-TYPE VEHICLES)
1
2
4
5
6
7
8
9
10
3
S7 00 640
Removing the wheel hub
1. Remove the hub cap (1) using special tool
(DAF no. 1329498).
2. Lift the leading rear axle and support it
properly.
3. Remove the split pin (2) and the hub nut (3).
4. Remove the outer wheel bearing (4).
5. Remove the hub (6) with the wheel.
Installing the wheel hub
1. Apply new grease to the hub (6).
2. Install the hub with the wheel.
3. Install the outer wheel bearing (4).
4. Fit the hub nut (3).
5. Adjust the wheel bearing play, see chapter
“Inspection and adjustment”.
6. Fit the s plit pin (2).
7. Lower the leading rear axle.
8. Fit the hub cap using special tool (DAF no.
1329894). Tighten the hub cap t o the
specified t orque, see “Technical data”.
9. Adjust the brakes.
