DAF 95XF - Page 149

95XF series Removal and installation
EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES
4-29
TRAILING AXLE 09N220
10
11
14
15
13
1
2
12
3
4
5
6
7
8
9
A800267
Removing the wheel hub
1. Remove the attachment bolts from the hub
cap and remove the hub cap (4).
2. Lift the t railing axle using the trailing axle
load transfer device.
3. Release the brakes.
4. Tap back the locking washer (6) and
remove t he lock nut (5) using special tool
(DAF no. 0535648).
5. Remove the locking washer (6) and the
circlip (7) from the axle journal.
6. Position a tyre lift under the wheel.
7. Remove the hub nut (9) using special tool
(DAF no. 0535648).
8. Remove the outer wheel bearing (10) from
the hub.
5
 200424
