EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES
Removal and installation 95XF series
4-32
5. Fit the wheel bearing (13) into the hub.
6. Fill the inside circumference of the hub with
wheel bearing grease.
7. Fit a new hub oil seal (14) in the hub.
8. Apply a little grease to the sealing lips of the
seal.
9. Position the wheel in front of the axle
journal using the tyre lift.
Fit the outer wheel bearing (10) into the hub
so that the outer wheel bearing can also
serve as a guide when installing the hub.
10. Slide t he hub over the axle journal. Do not
pry, as the oil seal (14) might be damaged
in the process.
11. Fit the hub nut (9) to the axle journal.
12. Adjust the s pecified wheel bearing play (see
chapter “Inspection and adjustment”) and fit
the c irclip (7) to the axle journal.
13. Fit a new locking washer (6) to the axle
journal. The cam of the locking washer
should f all into one of the holes of the circlip
(7).
14. Fit the lock nut (5) to the axle journal.
Tighten the lock nut (5) to the specified
tightening torque. See “Technical data”. Use
special tool (DAF no. 0535648).
15. Secure lock nut (5) by tapping back the
locking washer (6) against the side of the
lock nut.
16. Apply the specified grease to the front of the
outer wheel bearing.
17. Fit the hub cap (4) applying a sealant.
18. Adjust the brakes.
