95XF series Removal and installation
EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES
4-33
4.17 REMOVAL AND INSTALLATION, HUB OIL SEAL
FRONT AXLE/LEADING REAR AXLE AND TRAILING AXLES 9N075/09N220
Removing the hub oil seal
1. Remove the hub from the axle journal.
2. Drill two holes into the oil seal and screw
the s pecial tool (DAF no. 0484899) into the
oil seal. Pull the oil seal from the w heel hub
using t he special tool (DAF no. 0694928).
5
200424
