200706 9-7
VCI Configuration Manager
DAVIE XDc II
First connect the USB cable between the VCI and the DAVIE XDc II and
connect the VCI with the Vehicle Diagnostic Cable to the vehicle before
selecting the "Advanced Setup" screen.
Figure 9-7 Advanced Setup screen
Wireless Network Configuration
Network Name (SSID) Choose a Network Name (SSID) that is not
used by other Wireless Networks nearby.
IP-Address IP-Address of the VCI in the Wireless Network.
Subnetmask Subnet Mask for the VCI used in the Wireless
Network. Choose the appropriate subnet mask
for your network from the listed values.
Default Gateway Default Gateway used by VCI to connect to
other networks.
Network Type
Infrastructure: Connection with an Access-Point.
Ad-Hoc: For a direct connection between DAVIE XDC II
and VCI
Channel RF channel IS used for wireless
communication.
NOTE
Please take care. The selected RF channel has to conform to the local
regulations of your country.
