DAF DAVIE XDc II User Manual

2-4
©
200706
DAVIE XDc II
General Information
2.6 Technical Data
2.6.1 Laptop
See originally delivered documentation which is delivered with the laptop.
2.6.2 Vehicle Communication Interface (VCI)
Dimensions (W x D x H) 126 x 214 x47 mm
Weight 1.1 kg
Ambient conditions
Operation
Storage
Temperature gradient
Ambient temperature 0 to +50 °C
Relative humidity 10 to 90 %,
at max. +25 °C non-condensing
Ambient temperature -20 to +80 °C
Relative humidity <90% non-condensing)
5 °C/1 h
Power supply from the vehicle
electrical system
Rated voltages
Current consumption in the
load range
The VCI must be powered from the vehicle.
8 to 32 V DC
Max. 1 A
Power supply from the
rechargeable battery
Battery type
Buffered time
If external power is interrupted, the VCI will be
buffered by the rechargeable battery
NiMH 4,8V/1100mAh
Between 20 and 60 sec or no buffering
Communication
USB
Wireless LAN
For communication by wire to the DAVIE XDc II
For wireless communication to the DAVIE XDc II
via a (internal) wireless network card according
802.11b and 802.11g
