6-10
©
200706
DAVIE XDc II
Direct Testing
6.5.5 Test Plan
The test plan shows the list of the test procedures that have been executed.
The option "Test plan" is available during a diagnostic session. This plan is
organized by the DAVIE XDc II to provide useful information guiding the user to
a correct diagnosis as quickly as possible. The "Test plan" and the results will
be saved into the log file.
An example of a test plan shows the listing of the tests that have been executed.
Figure 6-11 Test plan
The user can select which part of the plan to execute next by pressing a
particular test, which will then be performed when the "Forward / >" button is
pressed.
The result of the test procedure is noted in front of the line. The following results
are possible:
1. OK The test procedure was completed with the result OK.
2. X The test procedure was completed with the result Not OK.
3. ? The result of the test procedure is unknown or the procedure was
interrupted. For example the test was closed by using the back button.
