5-4
©
200706
DAVIE XDc II
Vehicle Identification
5.3 Manual Identification
If the chassis number could not be found in the Parts Rapido Subset database,
the following message box will appear. It is possible to switch to manual
selection by selecting the "Manual" button or to return to the start screen by
selecting the "Exit" button. If pressed "Exit" then, update the Parts Rapido
Subset data by an update from Parts Rapido online and then try the automatic
identification again.
Figure 5-3 Note: Manual identification
NOTE
This message box will also appear when the Parts Rapido Subset is not
installed.
If the "Manual" button is selected, all possible systems will be displayed, even
systems that are not mounted on the vehicle. To select the required variants,
carry out the following steps:
1. Select a system by pressing the name of the system. The installation vari-
ants of the system are displayed automatically on the screen.
The system name is marked with a bar.
