200706 4-9
Operation
DAVIE XDc II
Figure 4-12 Start screen: User Login
4.5 Touchscreen (optional)
The entire touch-sensitive surface of the screen is designated as the
touchscreen.
The screen senses touch by a finger or delivered touch pen, thereby replacing
the conventional function of a mouse or keyboard. To select an element (text or
button), you must touch it on the screen.
As long as you are touching the screen, you can change the current selection.
When you stop touching the screen, the selected element is activated.
See for more features and settings of the touchscreen also the original
documentation which is delivered with the laptop.
NOTE
The screen reacts to all touch. When using the DAVIE XDc II, make sure it can
not be touched unintentionally by any equipment or people.
Do not use any other objects than your finger or delivered touch pen to operate
the screen. Using other objects can result in damage.
