200706 9-1
VCI Configuration Manager
DAVIE XDc II
9 VCI CONFIGURATION MANAGER
VCI Configuration Manger is a software program to:
• View the status of the VCI.
• To configure the VCI according to the user's requirements.
• To display VCI specific information.
• To configure the VCI Configuration Manger according to the user's
requirements.
9.1 VCI Tray Icon
The tray icon is similar to the VCI symbol on the front side of the housing and is
shown in the system tray. The tray icon displays the status of the VCI
connection.
The standard functionality connection status between DAVIE XDc II and VCI:
- White: Disconnected
- Blue: USB
-Green: WLAN
Figure 9-1 VCI Tray Icon
Hovering
When the mouse pointer hovers over the VCI tray icon for 1 second, the status
is displayed for approx. 5 seconds:
• Connection status between DAVIE XDc II and VCI: connected or
disconnected.
• Connection type: WLAN, USB or not available, if status is disconnected.
• Network name SSID, if available.
Double click left
With double click on the VCI tray icon with the left mouse button the VCI
Configuration Manager will be started directly.
