Dahua DH-XVR1B08 User Manual

Local Configurations 90
Figure 5-48
Configure the settings for the zero-channel parameters. See Table 5-17. Step 2
Parameter
Description
Enable
Enable zero-channel function.
Compression
In the Compression list, select the video compression standard
according to the device capability. The default is H.265.
Resolution
In the Resolution list, select the video resolution. The default is
704×576 (D1).
Frame Rate
(FPS)
Select a value between 1 and 25 for PAL standard, and between 1
and 30 for NTSC standard. The actual arrange is decided and
selected dependent on the Device capability.
Bit Rate (Kb/S)
The default value is 1024Kb/S. The actual arrange is decided and
selected dependent on the Device capability and frame rate.
Table 5-17
Click Apply to save the settings. Step 3
In the live interface on the web, click to select one of the
multi-channel modes, and then you can view the local video image.
5.2.6.4 Configuring TV
Not all models support this function.

Dahua DH-XVR1B08 Specifications

General

Audio Input	1 channel, RCA
Audio Output	1 channel, RCA
Video Output	1 HDMI, 1 VGA
USB	2 USB 2.0 ports
Power Supply	DC12V/1.5A
Video Compression	H.265/H.264
Analog Camera Input	8 channels, BNC
IP Camera Input	8
HDD	1 SATA port, up to 6TB
Network	1 RJ-45 port (10/100 Mbps)
Operating Temperature	-10°C to +55°C
Operating Humidity	10% to 90%
Max Recording Resolution	1080N/720p/960H/D1/CIF
