Local Configurations 123
Select the check box of the device. Step 2
Click Add. Step 3
The device is added into the Added Device area.
You can also double-click the device to add it into the Added Device area.
You can add devices in batches.
5.6.1.3 Adding Remote Devices Manually
On the Registration interface, click Manual Add. Step 1
The Manual Add interface is displayed. See Figure 5-85.
Figure 5-85
Configure the settings for the manual adding device parameters. See Table 5-30. Step 2
Parameter
Description
Channel
In the Channel list, select the channel that you want use on the
Device to connect the remote device.
Manufacturer
In the Manufacturer list, select the manufacturer of the remote
device.
IP Address
In the IP Address box, enter the IP address of remote device.
The default is 192.168.0.0 which the system cannot connect to.
RTSP Port
The default value setting is 554. You can enter the value according to
your actual situation.
HTTP Port
The default value setting is 80. You can enter the value according to
