Dahua DH-XVR1B08 User Manual

Local Configurations 145
Click on the time bar to select the end time, and then click to stop clipping. Step 3
Click . Step 4
The BACKUP dialog box is displayed. You can back up the files.
 You can clip the video of a single-channel or multiple channels.
 Maximum 1024 files can be backed up at one time.
 The files that are selected in the File List cannot be clipped.
5.9.3.4 Backing up Recorded Video
You can back up the recorded video file or splice video file into the USB storage device.
Select the recorded video file that you want to back up. You can select the following two
Step 1
types of files:
 Recorded video file: Click , the File List area is displayed. Select the file(s)
that you want to back up.
 Splice video file. For details about splicing video file, see "5.9.3.3 Clipping
Recorded Video."
Click . Step 2
The BACKUP dialog box is displayed. See Figure 5-108.
Figure 5-108
Click Backup. Step 3
If you do not want to back the file, clear the check box.

Dahua DH-XVR1B08 Specifications

General

Audio Input	1 channel, RCA
Audio Output	1 channel, RCA
Video Output	1 HDMI, 1 VGA
USB	2 USB 2.0 ports
Power Supply	DC12V/1.5A
Video Compression	H.265/H.264
Analog Camera Input	8 channels, BNC
IP Camera Input	8
HDD	1 SATA port, up to 6TB
Network	1 RJ-45 port (10/100 Mbps)
Operating Temperature	-10°C to +55°C
Operating Humidity	10% to 90%
Max Recording Resolution	1080N/720p/960H/D1/CIF
