Dahua DH-XVR1B08 User Manual

Local Configurations 160
Parameter
Description
Alarm Release
Click OK to clear all alarm output status.
Table 5-36
Click Apply to save the settings. Step 3
5.10.3.2 Configuring White Light
When the motion detection alarm is activated, the system links the camera to generate white
light alarm.
To use this function, connect at least one white light camera to your Device.
Select Main Menu > ALARM > ALARM OUTPUT > White Light. Step 1
The White Light interface is displayed. See Figure 5-124.
Figure 5-124
Configure the settings for the white light parameters. See Table 5-37. Step 2
Parameter
Description
Channel
In the Channel list, select a channel that is connected to a white
light camera.
Latch
Set a length of time for the Device to delay turning off alarm after
the alarm is cancelled. The value ranges from 5 seconds to 30
seconds, and the default value is 5 seconds.
Mode
Set the alarm mode of white light to be Solid on or Flash.

Dahua DH-XVR1B08 Specifications

General

Audio Input	1 channel, RCA
Audio Output	1 channel, RCA
Video Output	1 HDMI, 1 VGA
USB	2 USB 2.0 ports
Power Supply	DC12V/1.5A
Video Compression	H.265/H.264
Analog Camera Input	8 channels, BNC
IP Camera Input	8
HDD	1 SATA port, up to 6TB
Network	1 RJ-45 port (10/100 Mbps)
Operating Temperature	-10°C to +55°C
Operating Humidity	10% to 90%
Max Recording Resolution	1080N/720p/960H/D1/CIF
