Dahua DH-XVR1B08 User Manual

Local Configurations 245
Figure 5-206
Configure the settings for the SNMP parameters. See Table 5-66. Step 2
Parameter
Description
Enable
Enable the SNMP function.
Version
Select the check box of SNMP version(s) that you are using.
The default version is V3. There is a risk of select V1 or V2.
SNMP Port
Indicates the monitoring port on the agent program.
Read Community
Indicates the read/write strings supported by the agent program.
Write Community
Trap Address
Indicates the destination address for the agent program to send the
Trap information.
Trap Port
Indicates the destination port for the agent program to send the
Trap information.
Read Only User
Enter the user name that is allowed to access the Device and has
the "Read Only" permission.
Read/Write User
Enter the user name that is allowed to access the Device and has
the "Read and Write" permission.
Authentication Type
Includes MD5 and SHA. The system recognizes automatically.
Authentication
Password
Enter the password for authentication type and encryption type.
The password should be no less than eight characters.
Encryption
Password

Dahua DH-XVR1B08 Specifications

General

Audio Input	1 channel, RCA
Audio Output	1 channel, RCA
Video Output	1 HDMI, 1 VGA
USB	2 USB 2.0 ports
Power Supply	DC12V/1.5A
Video Compression	H.265/H.264
Analog Camera Input	8 channels, BNC
IP Camera Input	8
HDD	1 SATA port, up to 6TB
Network	1 RJ-45 port (10/100 Mbps)
Operating Temperature	-10°C to +55°C
Operating Humidity	10% to 90%
Max Recording Resolution	1080N/720p/960H/D1/CIF
