Dahua DH-XVR1B08 User Manual

Local Configurations 246
Parameter
Description
Encryption Type
In the Encryption Type list, select an encryption type. The default
setting is CBC-DES.
Table 5-66
Compile the two MIB files by MIB Builder. Step 3
Run MG-SOFT MIB Browser to load in the module from compilation. Step 4
On the MG-SOFT MIB Browser, enter the Device IP that you want to manage, and then Step 5
select the version number to query.
On the MG-SOFT MIB Browser, unfold the tree-structured directory to obtain the Step 6
configurations of the Device, such as the channels quantity and software version.
5.15.1.10 Configuring Multicast Settings
When you access the Device from the network to view the video, if the access is exceeded, the
video will not display. You can use the multicast function to group the IP to solve the problem.
Select Main Menu > NETWORK > MULTICAST. Step 1
The MULTICAST interface is displayed. See Figure 5-207.
Figure 5-207
Configure the settings for the multicast parameters. See Table 5-67. Step 2
Parameter
Description
Enable
Enable the multicast function.
IP Address
Enter the IP address that you want to use as the multicast IP.
The IP address ranges from 224.0.0.0 through 239.255.255.255.

Dahua DH-XVR1B08 Specifications

General

Audio Input	1 channel, RCA
Audio Output	1 channel, RCA
Video Output	1 HDMI, 1 VGA
USB	2 USB 2.0 ports
Power Supply	DC12V/1.5A
Video Compression	H.265/H.264
Analog Camera Input	8 channels, BNC
IP Camera Input	8
HDD	1 SATA port, up to 6TB
Network	1 RJ-45 port (10/100 Mbps)
Operating Temperature	-10°C to +55°C
Operating Humidity	10% to 90%
Max Recording Resolution	1080N/720p/960H/D1/CIF
