Dahua DH-XVR1B08 User Manual

Local Configurations 262
Figure 5-226
Click Add Group. Step 2
The Add Group interface is displayed. See Figure 5-227.
Figure 5-227
Configure the settings for the parameters of adding a group. See Table 5-72. Step 3
Parameter
Description
Group Name
Enter a name for the group.
Memo
Optional.
Enter a description of the account.

Dahua DH-XVR1B08 Specifications

General

Audio Input	1 channel, RCA
Audio Output	1 channel, RCA
Video Output	1 HDMI, 1 VGA
USB	2 USB 2.0 ports
Power Supply	DC12V/1.5A
Video Compression	H.265/H.264
Analog Camera Input	8 channels, BNC
IP Camera Input	8
HDD	1 SATA port, up to 6TB
Network	1 RJ-45 port (10/100 Mbps)
Operating Temperature	-10°C to +55°C
Operating Humidity	10% to 90%
Max Recording Resolution	1080N/720p/960H/D1/CIF
