Dahua DH-XVR1B08 User Manual

Local Configurations 275
Figure 5-243
Select the channels you want to configure, and select quota from the drop-down list of Step 2
corresponding HDD.
Click Apply to complete the settings.
Step 3
Click Statistics to view the quota of each channel in HDD. See Figure 5-244.
Figure 5-244

Dahua DH-XVR1B08 Specifications

General

Audio Input	1 channel, RCA
Audio Output	1 channel, RCA
Video Output	1 HDMI, 1 VGA
USB	2 USB 2.0 ports
Power Supply	DC12V/1.5A
Video Compression	H.265/H.264
Analog Camera Input	8 channels, BNC
IP Camera Input	8
HDD	1 SATA port, up to 6TB
Network	1 RJ-45 port (10/100 Mbps)
Operating Temperature	-10°C to +55°C
Operating Humidity	10% to 90%
Max Recording Resolution	1080N/720p/960H/D1/CIF
