Local Configurations 288
End Port
When Type is IP Address, they can be configured. Start Port and
End Port can be configured only in Network Access Type.
Start Address
Enter Start Address and End Address of IP Segment.
When Type is IP Segment, they can be configured.
End Address
MAC Address
Enter MAC Address that is allowed or forbidden.
When Type is MAC Address, it can be configured.
Table 5-77
Click Apply to complete the settings. Step 4
5.19.3.2 Configuring System Service Settings
You can enable or disable the system internal services.
Select Main Menu > SYSTEM > SECURITY > System Service. Step 1
The System Service interface is displayed. See Figure 5-262.
Figure 5-262
Configure the parameters. For details, see Table 5-78. Step 2
Parameter
Description
Password Reset
Enable or disable the password reset function. It is enabled
by default.
If the password reset function is disabled, you can find back
the password by the security questions. Make sure you have
configured the security questions.

Dahua DH-XVR1B08 Specifications

General

Audio Input	1 channel, RCA
Audio Output	1 channel, RCA
Video Output	1 HDMI, 1 VGA
USB	2 USB 2.0 ports
Power Supply	DC12V/1.5A
Video Compression	H.265/H.264
Analog Camera Input	8 channels, BNC
IP Camera Input	8
HDD	1 SATA port, up to 6TB
Network	1 RJ-45 port (10/100 Mbps)
Operating Temperature	-10°C to +55°C
Operating Humidity	10% to 90%
Max Recording Resolution	1080N/720p/960H/D1/CIF
