Dahua DH-XVR1B08 User Manual

Local Configurations 48
Figure 5-2
Tick the check box that I have read and agree to all terms, and then click Next. Step 4
The System Zone and System Time interface is displayed. See Figure 5-3.
Figure 5-3
Select system zone, configure system time, and then click Next. Step 5
The Enter Password interface is displayed. See Figure 5-4.
Figure 5-4
Configure the password information for admin. For details, see Table 5-1. Step 6
Parameter
Description

Dahua DH-XVR1B08 Specifications

General

Audio Input	1 channel, RCA
Audio Output	1 channel, RCA
Video Output	1 HDMI, 1 VGA
USB	2 USB 2.0 ports
Power Supply	DC12V/1.5A
Video Compression	H.265/H.264
Analog Camera Input	8 channels, BNC
IP Camera Input	8
HDD	1 SATA port, up to 6TB
Network	1 RJ-45 port (10/100 Mbps)
Operating Temperature	-10°C to +55°C
Operating Humidity	10% to 90%
Max Recording Resolution	1080N/720p/960H/D1/CIF
