Dahua DH-XVR1B08 User Manual

Local Configurations 66
 If the Device has not been initialized, Tap Device Initialization to perform
initializing by following the onscreen instructions.
 If the Device has been initialized, you can start adding it directly.
Tap Add Device. 4)
The Add Device interface is displayed. See Figure 5-25.
You can add wireless device or wired device. The Manual takes adding wired
device as an example.
Figure 5-25
Tap P2P. 5)
The P2P interface is displayed. See Figure 5-26.

Dahua DH-XVR1B08 Specifications

General

Audio Input	1 channel, RCA
Audio Output	1 channel, RCA
Video Output	1 HDMI, 1 VGA
USB	2 USB 2.0 ports
Power Supply	DC12V/1.5A
Video Compression	H.265/H.264
Analog Camera Input	8 channels, BNC
IP Camera Input	8
HDD	1 SATA port, up to 6TB
Network	1 RJ-45 port (10/100 Mbps)
Operating Temperature	-10°C to +55°C
Operating Humidity	10% to 90%
Max Recording Resolution	1080N/720p/960H/D1/CIF
