10 Spyder3 S3-14 and S3-24 Monochrome Camera User's Manual
03-032-20117-01 Teledyne DALSA
Test conditions unless otherwise noted
 12-bit values, Flat Field Correction (FFC) enabled.
 CCD Pixel Rate: 40 megapixels/ second per sensor tap.
 Line Rate: 5000 Hz.
 Nominal Gain setting unless otherwise specified.
 Light Source: Broadband Quartz Halogen, 3250k, with 750 nm high pass filter installed.
 Ambient test temperature 25 °C.
 Unless specified, all values are referenced at 12 bit.
 Exposure mode disabled.
 Unless specified, dual line mode.
Notes
1. PRNU measured at 50% SAT.
Certifications
Table 4: EMC Compliance Standards
Compliance
The CE Mark, FCC Part 15, and Industry Canada ICES-003 Evaluation of the DALSA Spyder3 CL S3-14and S3-24
cameras meet the following requirements:
CISPR 22, EN 55022 and EN 61326 Class A Emissions Requirements, EN 55024, and EN 61326 Immunity to
Disturbances
Responsivity
Spectral Responsivity. Nominal Gain
0
250
500
750
1000
1250
1500
1750
2000
2250
2500
400 500 600 700 800 900 1000 1100
Wavelength (nm)
Responsivity {DN/(nJ/cm²)}
High Sensitivity Mode
Low Sensitivity Mode
