8 Spyder3 S3-14 and S3-24 Monochrome Camera User's Manual
03-032-20117-01 Teledyne DALSA
The Spyder3 CL camera is available in these models.
Table 1: Spyder3 CL Camera Models Overview
Model Number
Description
S3-24-01K40-00-R
1k resolution, 2 sensor taps. Base Camera Link configuration.
S3-24-02K40-00-R
2k resolution, 2 sensor taps. Base Camera Link configuration.
S3-14-01K40-00-R
1k resolution, 1 sensor tap. Base Camera Link configuration.
S3-14-02K40-00-R
2k resolution, 1 sensor tap. Base Camera Link configuration.
S3-24-04k40-00-R
4k resolution, 2 sensor taps. Base Camera Link configuration.
Camera Performance Specifications
Table 2: Camera Performance Specifications
Feature / Specification
1k
2k
4k
Imager Format
dual line scan
Resolution
1024 pixels
2048 pixels
4096 pixels
Pixel Fill Factor
100 %
Pixel Size
14 µm x 14 µm
10 µm x 10 µm
Sensitivity Mode
High, low, or tall pixel
Antiblooming
100 x
Gain Range
± 10 dB
Speed
1k
2k
4k
Data Rate
40 mp / s and 80 mp / s
80 mp / s
Maximum Line
Rate
2 tap model
68 kHz (80 MHz)
36 kHz (80 MHz)
18.5 kHz
1 tap model
36 kHz (40 MHz)
18.5 kHz (40 MHz)
NA
Optical Interface
1k and 2k
4k
Lens Mount
M42 x 1, C and F*
M58 x 0.75, F*
Focal Length
6.56 mm ± 0.25
Sensor Alignment
x ± 50 µm
y ± 50 µm
z ± 0.25 mm
z ± 0.2 º
Mechanical Interface
1k and 2k
4k
Camera Size
72 mm (h) x 60 mm (l) x 60 mm (w)
60 mm (h) x 72 mm (l) x 60 mm (w)
Mass
< 300 g
Connectors
6 pin male Hirose power
MDR26 female data connector
Electrical Interface
1k and 2k
4k
Input Voltage
+ 12 to +15 Volts DC
Power Dissipation
< 5 W (1k and 2k)
< 7 W (4k)
