Dalsa Spyder3 S3-14-01k40-00-R - Operating Mode

80 Spyder3 S3-14 and S3-24 Monochrome Camera User's Manual
03-032-20117-01 Teledyne DALSA
SRM 0, Auto Mode.
Time Period
Operating Region
Refer to Figure 28.
Operating Mode
T
0
Dark Current Dump state
T
1
Immediate Readout state
SRM 0, Auto Mode.
Time Period
Operating Region
Refer to Figure 28.
Operating Mode
T
0
Immediate Readout state
T
1
Dark Current Dump state
T
2
Immediate Readout state
SRM 2, Immediate Readout Mode.
Time Period
Operating Region
Refer to Figure 28.
Operating Mode
T
0
Dark Current Dump state
T
1
Immediate Readout state
Dark Current Dump to Immediate Readout (T
INT
< #)
EXSYNC
T
DUMP
T
INT
LVAL
Valid
F
DUMP
F
IMMEDIATE
