Spyder3 S3-14 and S3-24 Monochrome Camera User's Manual 33
Teledyne DALSA 03-032-20117-01
Factory Settings
On first initialization, the camera operates using the factory settings. You can restore the original factory
settings at any time using the command rfs.
User Settings
You can save or restore your user settings to non-volatile memory using the following commands. Pixel
coefficients and LUTs are stored separately from other data.
To save all current user settings to non-volatile memory, use the command wus. The camera will
automatically restore the saved user settings when powered up. Note: While settings are being
written to nonvolatile memory, do not power down camera or camera memory may be
corrupted.
To restore the last saved user settings, use the command rus.
To save the current pixel coefficients, use the command wpc and wfc.
To restore the last saved pixel coefficients, use the command lpc.
To write LUTs, use the wil command.
Current Session Settings
These are the current operating settings of your camera. To save these settings to non-volatile memory,
use the command wus.
Camera Output Format
How to Configure Camera Output
Using the camera link mode and pixel readout direction commands
Use the camera link mode (clm) comm and to determine the camera’s Cam era Link configu ration, the
number of output taps, and the bit depth. Use the pixel readout direction (smm) command to select the
cam era’s pixel read ou t d irection.
The following tables summarize the possible camera configurations for each of the S3-xx camera models.
Table 11: Data Readout Configurations
smm 0 increment =1
smm 1 increment = -1
smm 0 = CL tap 1 (1-1024)
smm 1 = CL tap 1 (1024-1)
smm 0 = CL tap 1 (1-2048)
smm 1 = CL tap 1 (2048-1)
smm 0 = CL tap 1 (1-1024)
smm 1 = CL tap 1 (1024-1)
smm 0 = CL tap 1 (1-2048)
smm 1 = CL tap 1 (2048-1)
smm 0 = CL tap 1 (1-512)
CL tap 2 (513-1024)
smm 1 = CL tap 1 (1024-513)
CL tap 2 (512-1)
smm 0 = CL tap 1 (1-1024)
