Dalsa Spyder3 S3-14-01k40-00-R User Manual

Spyder3 S3-14 and S3-24 Monochrome Camera User's Manual 47
Teledyne DALSA 03-032-20117-01
Data Processing
Setting a Region of Interest (ROI)
Sets the pixel range used to collect the end-of-line statistics and sets the region of pixels used in the ccg, gl, gla,
ccf, and ccp commands.
In most applications, the field of view exceeds the required object size and these extraneous areas should
be ignored. It is recommended that you set the region of interest a few pixels inside the actual useable
Camera Link Command
Parameter
Description
Notes
roi x1 y1 x2 y2
x1: Pixel start number. Must be less than the pixel end
number in a range from 1 to sensor resolution.
y1: Column start number. Since the Spyder3 CL is a line
scan camera, this value must be 1.
x2: Pixel end number. Must be greater than the pixel
start number in a range from 1 to sensor
resolution
y2: Column end number. Since the Spyder3 CL is a line
scan camera, this value must be 1.
To return the current region of
interest, use the commands gcp or
get roi.
Example
roi 10 1 50 1
