60 Spyder3 S3-14 and S3-24 Monochrome Camera User's Manual
03-032-20117-01 Teledyne DALSA
Enabling and Disabling Pixel Coefficients
Enables and disables FPN and PRNU coefficients
Camera Link Command
Parameter
Description
Notes
epc i i
i FPN coefficients.
0 = FPN coefficients disabled
1 = FPN coefficients enabled
i PRNU coefficients.
0 = PRNU coefficients disabled
1 = PRNU coefficients enabled
Example
epc 0 1
End-of-line Sequence
To aid in debugging, the camera can produce an end-of-line sequence that provides basic calculations
including "line counter", "line sum", "pixels above threshold", "pixels below threshold", and "derivative
line sum" within the region of interest. These calculations can be used to perform aoc algorithms or
indicate objects of interest.
To further aid in debugging and cable/ data path integrity, the first three pixels after Line Valid are "aa",
"55", "aa". Refer to the following table. These statistics are calculated for the pixels within the r egion of
interest.
Camera Link Command
Parameter
Description
Notes
els i
0 Disable end-of-line sequence
1 Enable end-of-line sequence
LVAL is not high during the end-of-line
statistics.
Example
els 1
Table 14: End-of-Line Sequence Description
Location
Value
Description
1
A’s
By ensuring these values consistently toggle between "aa" and
"55", you can verify cabling (i.e. no stuck bits)
2
5’s
3
A’s
4
4 bit counter LSB justified
Counter increments by 1. Use this value to verify that every line
is output
5
Line sum (7…0)
Use these values to help calculate line average and gain
6
Line sum (15…8)
7
Line sum (23…16)
