Spyder3 S3-14 and S3-24 Monochrome Camera User's Manual 61
Teledyne DALSA 03-032-20117-01
Location
Value
Description
8
Line sum (31…24)
9
Pixels above threshold (7…0)
Monitor these values (either above or below threshold) and
adjust camera digital gain and background subtract to maximize
scene contrast. This provides a basis for automatic gain control
(AGC)
10
Pixels above threshold
(15…8)
11
Pixels below threshold (7…0)
12
Pixels below threshold (15…8)
13
Differential line sum (7..0)
Use these values to focus the camera. Generally, the greater the
sum the greater the image contrast and better the focus.
14
Differential line sum (15…8)
15
Differential line sum (23…16)
16
Differential line sum (31…24)
Setting Thresholds
Setting an Upper Threshold
Sets the upper threshold limit to report in the end -of-line sequence.
Camera Link Command
Parameter
Description
Notes
sut i
Upper threshold limit in range from 0
to 4095.
LVAL is not high during the end-of-line statistics.
Example
sut 1024
Setting a Lower Threshold
Sets the lower threshold limit to report in the end -of-line sequence.
Camera Link Command
Parameter
Description
Notes
slt i
Upper threshold limit in range from 0
to 4095.
LVAL is not high during the end-of-line statistics.
Example
slt 1024
