30 Spyder3 S3-14 and S3-24 Monochrome Camera User's Manual
03-032-20117-01 Teledyne DALSA
To read all current camera settings, use the command:
gcp
GCP Screen
Description
GENERAL CAMERA SETTINGS
Camera Model No.:
S3-x0-0xK40-00-R
Camera model number.
Camera Serial No.:
xxxxxxxxx
Camera serial number.
Firmware Version:
xx-xx-xxxxx-xx
Firmware design revision number.
CCI Version:
xxxxx.xx
CCI version number.
FPGA Version:
xxx.xx
FPGA revision number.
UART Baud Rate:
9600
Serial communication connection speed set
with the sbr command.
Dual Scan Mode:
High Sensitivity
Current sensitivity mode set with the smm
command. See section Sensitivity Mode for
details.
Camera Link Mode:
2 taps, 8 bits
Current bit depth setting set with the clm
command.
Mirroring Mode
0, left to right
Tap readout direction: left to right, or right to
left. Set with the smm command.
Readout Mode
Off
Current readout mode status. Set using the
srm command.
Cable Parameter
200
The cable parameter. Set using the scb
command.
Exposure Mode:
2
Current exposure mode value set with the sem
command. See the Setting the Camera Link
Mode section for details.
SYNC Frequency:
5000 Hz
Current line rate. Value is set with the ssf
command. See the Setting the Camera Link
Mode section for details.
Exposure Time:
200 µSec
Current exposure time setting. Value is set
with the set command. See the Setting the
Camera Link Mode section for details.
CCD Direction:
internal/forward
Current direction setting set with scd
command. Refer to section
CCD Shift Direction for details.
Horizontal Binning:
1
Current horizontal binning factor set with the
sbh command.
Video Mode:
video
Current video mode value set with the svm
command. See section Generating a Test
Pattern for details.
Region of Interest:
(1,1) to (1024, 1)
Region of interest size set with the roi
command. See section Setting a Region of
Interest (ROI) for details.
End-Of-Line
Sequence:
on
States whether an end of line sequence is
turned on or off. Set using the els command.
See section End-of-line Sequence for details.
FFC Coefficient Set:
0
Current pixel coefficient set loaded. Refer to
section Saving and Restoring PRNU and FPN
Coefficients for details.
