Spyder3 S3-14 and S3-24 Monochrome Camera User's Manual 31
Teledyne DALSA 03-032-20117-01
FPN Coefficients:
off
States whether FPN coefficients are on or off.
Set with the epc command. Refer to section
Analog and Digital Signal Processing Chain
for details.
PRNU Coefficients:
off
States whether PRNU coefficients are on or off.
Set with the epc command. Refer to section
Analog and Digital Signal Processing Chain
for details.
Number of Line
Samples:
1024
Number of lines samples set with the css
command. See section Returning Video
Information for details.
Upper Threshold
3600
Upper threshold value set with the sut
command.
See section End-of-line Sequence for details.
Lower Threshold
400
Lower threshold value set with the slt
command. See section End-of-line Sequence
for details.
Analog Gain (dB):
0.0 0.0
Analog gain settings set with the sag
command. See section Analog and Digital
Signal Processing Chain for details.
Analog Gain
Reference(dB):
0.0 0.0
Analog reference gain set with the ugr
command.
See section Analog and Digital Signal
Processing Chain for details.
Total Analog Gain
(dB):
5.5 5.5
This is the sum of the analog gain and analog
gain reference values and is the total analog
gain being used by the camera.
Analog Offset:
70 70
Analog offset settings set with the sao
command. See section Analog and Digital
Signal Processing Chain for details.
Digital Offset:
0 0
Digital offset settings set with the sdo
command. See section Analog and Digital
Signal Processing Chain for details.
Background Subtract:
0 0
Background subtract settings set with the ssb
command. See section Analog and Digital
Signal Processing Chain for details.
System Gain (DN):
4096 4096
Digital gain settings set with the ssg
command. See section Analog and Digital
Signal Processing Chain for details.
